We are the authorised SoulNote distributor for Singapore. Audio Basic 1 Coleman Street #02-12. The Adelphi. Tel: 6338 3245 SPECIFICATIONS Supported sampling frequency ZERO LINK, USB: Max. 768kHz (PCM) / Max. 22.6MHz (DSD) Coaxial, AES/EBU: Max. 192kHz (PCM) / Max. 2.8MHz (DSD64 DoP v1.1) PCM quantization bit rate ZERO LINK, USB: 16bit, 24bit, 32bit Coaxial, AES/EBU: 16bit, 24bit Digital input ZERO LINK, USB (Typ B) 2, coaxial (S/PDIF), AES/EBU External clock input 10MHz (SMA 50ohms) Analog output XLR x1, RCA x1 Analog output level XLR: 5,6Vrms RCA: 2,8Vrms Frequency characteristic 2Hz bis 120kHz (+0/-1dB) S/N ratio 110dB Total harmonic distortion 0,008% (NOS/176,4kHz) Analog filter Primary passive type Power voltage 230V AC 50Hz Power consumption 48W Maximum external dimensions Main unit: 454(W) × 174(H) × 407(D)mm Weight 28kg
